16.19m Diesel Boom Lift - Manitou 180ATJ
16.19m Diesel Boom Lift - Manitou 180ATJ
This machine or equivalent available for UK wide delivery
Applications & uses of machine
59.68ft
Working height230kg
Platform capacityOutdoor
EnvironmentUp & Over
MovementIPAF: 3b
IPAF RatingEven & Rough
Ground- 45%
Up to 45%
Max gradient
16.19m Diesel Boom Lift - Manitou 180ATJ
Equip yourself with a Manitou 180 ATJ lifting platform to easily navigate sites and work at height safely. Thanks to its articulated telescopic boom, this model offers precision of movement and allows users to easily access the working area. It's compactness and all-terrain capability make it an ideal solution for driving on rough grounds.
Technical Specification
| Power Type | Diesel |
|---|---|
| Extended Max Height | 53.12ft |
| Working Height | 59.68ft |
| Platform Length | 2.62ft |
| Platform Length Extended | 2.62ft |
| Platform Width | 5.91ft |
| Outreach | 34.48ft |
| Up & Over Height | 22.97ft |
| Swing | 350° |
| Machine Length | 25.56ft |
| Machine Width | 7.61ft |
| Stowed Height | 8.4ft |
| Stowed Height Rails Down | 8.4ft |
| Max Load Capacity | 230kg |
| Weight | 7430kg |
| Wheelbase | 7.22ft |
| Gradeability | 45% |
| Environment | Outdoor |
| Surface Outdoor | Even & Rough |
| Tyres | Rough Terrain |
| Maximum Ground Bearing Pressure | 10daN/cm2 |
