15.1m Battery Scissor Lift - PB Lift 171-12ES
15.1m Battery Scissor Lift - PB Lift 171-12ES
This machine or equivalent available for UK wide delivery
Applications & uses of machine
56.1ft
Working height400kg
Platform capacityIndoor / Outdoor
EnvironmentStraight Up Only
MovementIPAF: 3a
IPAF RatingFinished
Indoor useEven
Outdoor use- 25%
Up to 25%
Max gradient
Platform Height
Max Platform Height:49.54ft
15.1m Battery Scissor Lift - PB Lift 171-12ES
With a working height of 17.10m, this battery operated scissor lift is drivable at full height. Its non-marking tyres and small turning radius make it suitable for a wide range of indoor and outdoor work. Its patented PB support system automatically levels the machine within a few seconds, giving it optimal stability.
Technical Specification
| Power Type | Battery |
|---|---|
| Extended Max Height | 49.54ft |
| Working Height | 56.1ft |
| Platform Length | 9.51ft |
| Platform Length Extended | 12.8ft |
| Platform Width | 3.9ft |
| Machine Length | 10.76ft |
| Machine Width | 4ft |
| Stowed Height | 7.74ft |
| Stowed Height Rails Down | 7.74ft |
| Max Load Capacity | 400kg |
| Weight | 5710kg |
| Gradeability | 25% |
| Environment | Indoor / Outdoor |
| Surface Indoor | Finished |
| Surface Outdoor | Even |
| Tyres | Non Marking |
