8m Battery Scissor Lift - Haulotte Compact 10N
8m Battery Scissor Lift - Haulotte Compact 10N
This machine or equivalent available for UK wide delivery
Applications & uses
32.15ft
Working heightIndoor
EnvironmentStraight Up Only
MovementIPAF: 3a
IPAF RatingFinished
Ground- 23%
Up to 23%
Max gradient
Platform Height
Max Platform Height:26.25ft
8m Battery Scissor Lift - Haulotte Compact 10N
The Compact 10N is designed to operate in the most congested areas with a narrow machine width of just 81cm. Driveable at full height and featuring an extendable platform, the Compact 10N can reach a working height of 10m.
Technical Specification
| Power Type | Battery |
|---|---|
| Extended Max Height | 26.25ft |
| Working Height | 32.15ft |
| Platform Length | 7.55ft |
| Platform Length Extended | 10.56ft |
| Platform Width | 2.66ft |
| Machine Length | 8.17ft |
| Machine Width | 2.66ft |
| Stowed Height | 7.71ft |
| Stowed Height Rails Down | 6.36ft |
| Max Load Capacity | 230kg |
| Weight | 2160kg |
| Wheelbase | 6.1ft |
| Gradeability | 23% |
| Environment | Indoor |
| Surface Indoor | Finished |
| Tyres | Non Marking |
