14.4m Diesel Boom Lift - ATN Zebra 16
14.4m Diesel Boom Lift - ATN Zebra 16
This machine or equivalent available for UK wide delivery
Applications & uses of machine
53.81ft
Working height230kg
Platform capacityOutdoor
EnvironmentUp & Over
MovementIPAF: 3b
IPAF RatingEven & Rough
Ground- 45%
Up to 45%
Max gradient
14.4m Diesel Boom Lift - ATN Zebra 16
The Zebra 16 is a versatile offroad 4x4 articulating boom lift, with a working heigh of 16.4m and a lift capacity of 230kg. Thanks to its useful occillating axle, 4 wheel drive and high traction tyres, the Zebra 16 is ideal for outdoor applications on all terrains
Technical Specification
| Power Type | Diesel |
|---|---|
| Extended Max Height | 47.24ft |
| Working Height | 53.81ft |
| Platform Length | 2.82ft |
| Platform Length Extended | 2.82ft |
| Platform Width | 5.91ft |
| Outreach | 30.84ft |
| Up & Over Height | 24.28ft |
| Swing | 360° |
| Machine Length | 23.23ft |
| Machine Width | 7.19ft |
| Stowed Height | 7.38ft |
| Stowed Height Rails Down | 7.38ft |
| Max Load Capacity | 230kg |
| Weight | 7200kg |
| Wheelbase | 6.89ft |
| Gradeability | 45% |
| Environment | Outdoor |
| Surface Outdoor | Even & Rough |
| Tyres | Rough Terrain |
| Maximum Ground Bearing Pressure | 1393 kn/m2 |
