7.6m Battery Push Around Vertical - Genie AWP 25S
7.6m Battery Push Around Vertical - Genie AWP 25S
This machine or equivalent available for UK wide delivery
Applications & uses of machine
31.5ft
Working height159kg
Platform capacityIndoor / Outdoor
EnvironmentStraight Up Only
MovementIPAF: PAV
IPAF RatingFinished
Indoor useEven
Outdoor use
Working Envelope
Max Platform Height:24.93ft
7.6m Battery Push Around Vertical - Genie AWP 25S
The Genie AWP-20s is an aerial work platform that can be used in a variety of environments, its lightweight design makes it easy to load an transport. Features a working height or 9.57m and a capacity of 159kg.
Technical Specification
| Power Type | Battery |
|---|---|
| Extended Max Height | 24.93ft |
| Working Height | 31.5ft |
| Platform Length | 2.26ft |
| Platform Width | 2.17ft |
| Machine Length | 4.3ft |
| Machine Width | 2.43ft |
| Stowed Height | 6.5ft |
| Stowed Height Rails Down | 6.5ft |
| Max Load Capacity | 159kg |
| Weight | 330kg |
| Gradeability | null% |
| Environment | Indoor / Outdoor |
| Surface Indoor | Finished |
| Surface Outdoor | Even |
| Tyres | Non Marking |
